引导编辑：突破碱基编辑类型的新技术

doi:10.16288/j.yczz.22-156

遗传 ›› 2022, Vol. 44 ›› Issue (11): 993-1008.doi: 10.16288/j.yczz.22-156

引导编辑：突破碱基编辑类型的新技术

刘尧(), 周先辉, 黄舒泓, 王小龙()

西北农林科技大学，动物科技学院/农业农村部动物生物育种国际联合研究中心/陕西省动物遗传育种与繁殖重点实验室，杨凌 712100

收稿日期:2022-07-23 修回日期:2022-09-01 出版日期:2022-11-20 发布日期:2022-09-16
通讯作者: 王小龙 E-mail:yaoliu@nwafu.edu.cn;xiaolongwang@nwafu.edu.cn
作者简介:刘尧，在读博士研究生，专业方向：动物遗传育种。E-mail: yaoliu@nwafu.edu.cn。
基金资助:
国家自然科学基金项目(31972526);国家自然科学基金项目(32161143010)

Prime editing: a search and replace tool with versatile base changes

Yao Liu(), Xianhui Zhou, Shuhong Huang, Xiaolong Wang()

College of Animal Science and Technology/International Joint Research Center of Animal Bio-breeding, Ministry of Agriculture and Rural Affairs/Shaanxi Key Laboratory of Animal Genetic Breeding and Reproduction, Northwest A & F University, Yangling 712100, China

Received:2022-07-23 Revised:2022-09-01 Online:2022-11-20 Published:2022-09-16
Contact: Wang Xiaolong E-mail:yaoliu@nwafu.edu.cn;xiaolongwang@nwafu.edu.cn
Supported by:
the National Natural Science Foundation of China(31972526);the National Natural Science Foundation of China(32161143010)

摘要/Abstract

摘要：

引导编辑技术(prime editing)是一种基于CRISPR/Cas系统的新型基因编辑技术。引导编辑器(prime editor, PE)的效应蛋白是逆转录酶与具有单链切割活性的nCas9(H840A)的融合蛋白，被称为PE2；其向导RNA是通过在sgRNA的3′末端增加逆转录模板和引物结合位点序列构成，被称为pegRNA。PE系统可以实现所有12种类型的碱基突变，还可以实现短的插入删除编辑，及多种编辑类型的组合。自2019年被开发以来，因其编辑类型多样化及高特异性等优势，PE已经被成功地应用在多种动植物及细菌中，同时在基因治疗和农业育种等领域也展现出良好的应用前景。本文对PE系统的开发过程、特点、优化、应用、安全风险等方面进行了系统介绍，并对其发展前景进行了展望，以期有助于相关领域研究人员对PE系统的了解与应用。

关键词: 引导编辑器, CRISPR/Cas9, 优化, 应用

Abstract:

Prime editing is a newly developed CRISPR/Cas system-based genome editing technique. The effector of prime editor (PE) is termed PE2, which is generated by fusing a reverse transcriptase (RT) with a Cas9 H840A nickase. The guide RNA of PE is termed prime editing guide RNA (pegRNA), which consists of a single guide RNA (sgRNA) with a 3′ extension containing the RT template (RTT) and primer binding site (PBS). PE can install all 12 types of point mutations, small insertions and deletions and combinations thereof. Since its emergence in 2019, with the high versatility and specificity, PE has been applied to many living organisms, including animals, plants and bacteria. This led to many explorations of PE on gene therapy and genetic improvement in agriculture. In this review, we systematically describe the development, characteristics, optimizations, applications and security of PE. In addition, we discuss the future applications of PE. We expect that this review will help researchers to grasp and better use PE.

Key words: prime editor, CRISPR/Cas9, optimization, application

刘尧, 周先辉, 黄舒泓, 王小龙. 引导编辑：突破碱基编辑类型的新技术[J]. 遗传, 2022, 44(11): 993-1008.

Yao Liu, Xianhui Zhou, Shuhong Huang, Xiaolong Wang. Prime editing: a search and replace tool with versatile base changes[J]. Hereditas(Beijing), 2022, 44(11): 993-1008.

图/表 6

图1

表1

图2

表2

图3

表3

参考文献 97

[1]	Cong L, Ran FA, Cox D, Lin SL, Barretto R, Habib N, Hsu PD, Wu XB, Jiang WY, Marraffini LA, Zhang F. Multiplex genome engineering using CRISPR/Cas systems. Science, 2013, 339(6121): 819-823. doi: 10.1126/science.1231143
[2]	Komor AC, Kim YB, Packer MS, Zuris JA, Liu DR. Programmable editing of a target base in genomic DNA without double-stranded DNA cleavage. Nature, 2016, 533(7603): 420-424. doi: 10.1038/nature17946
[3]	Gaudelli NM, Komor AC, Rees HA, Packer MS, Badran AH, Bryson DI, Liu DR. Programmable base editing of AT to GC in genomic DNA without DNA cleavage. Nature, 2017, 551(7681): 464-471. doi: 10.1038/nature24644
[4]	Ceccaldi R, Rondinelli B, D'Andrea AD. Repair pathway choices and consequences at the double-strand break. Trends Cell Biol, 2016, 26(1): 52-64. doi: S0962-8924(15)00142-7 pmid: 26437586
[5]	Zong Y, Gao CX. Progress on base editing systems. Hereditas (Beijing), 2019, 41(9): 777-800.
	宗媛, 高彩霞. 碱基编辑系统研究进展. 遗传, 2019, 41(9): 777-800.
[6]	Anzalone AV, Randolph PB, Davis JR, Sousa AA, Koblan LW, Levy JM, Chen PJ, Wilson C, Newby GA, Raguram A, Liu DR. Search-and-replace genome editing without double-strand breaks or donor DNA. Nature, 2019, 576(7785): 149-157. doi: 10.1038/s41586-019-1711-4
[7]	Wang XL, Huang XX, Liu Y. Search-and-replace editing of genetic information. Front Agr Sci Eng, 2020, 7(2): 231-232. doi: 10.15302/J-FASE-2020322
[8]	Lin QP, Zong Y, Xue CX, Wang SX, Jin S, Zhu ZX, Wang YP, Anzalone AV, Raguram A, Doman JL, Liu DR, Gao CX. Prime genome editing in rice and wheat. Nat Biotechnol, 2020, 38(5): 582-585. doi: 10.1038/s41587-020-0455-x pmid: 32393904
[9]	Lin JX, Liu XC, Lu ZY, Huang SS, Wu SS, Yu WX, Liu Y, Zheng XG, Huang XX, Sun Q, Qiao YB, Liu Z. Modeling a cataract disorder in mice with prime editing. Mol Ther Nucleic Acids, 2021, 25 494-501. doi: 10.1016/j.omtn.2021.06.020
[10]	Liu Y, Li XY, He ST, Huang SH, Li C, Chen YL, Liu Z, Huang XX, Wang XL. Efficient generation of mouse models with the prime editing system. Cell Discov, 2020, 6(1): 27. doi: 10.1038/s41421-020-0165-z pmid: 32351707
[11]	Jang H, Jo DH, Cho CS, Shin JH, Seo JH, Yu G, Gopalappa R, Kim D, Cho SR, Kim JH, Kim HH. Application of prime editing to the correction of mutations and phenotypes in adult mice with liver and eye diseases. Nat Biomed Eng, 2022, 6(2): 181-194. doi: 10.1038/s41551-021-00788-9
[12]	Liu Y, Yang G, Huang SH, Li XY, Wang X, Li GL, Chi T, Chen YL, Huang XX, Wang XL. Enhancing prime editing by Csy4-mediated processing of pegRNA. Cell Res, 2021, 31(10): 1134-1136. doi: 10.1038/s41422-021-00520-x pmid: 34103663
[13]	Zhang GQ, Liu Y, Huang SS, Qu SY, Cheng DL, Yao Y, Ji QJ, Wang XL, Huang XX, Liu JH. Enhancement of prime editing via xrRNA motif-joined pegRNA. Nat Commun, 2022, 13(1): 1856. doi: 10.1038/s41467-022-29507-x pmid: 35387980
[14]	Li XY, Wang X, Sun WJ, Huang SS, Zhong MT, Yao Y, Ji QJ, Huang XX. Enhancing prime editing efficiency by modified pegRNA with RNA G-quadruplexes. J Mol Cell Biol, 2022, 14(4): mjac022. doi: 10.1093/jmcb/mjac022
[15]	Nelson JW, Randolph PB, Shen SP, Everette KA, Chen PJ, Anzalone AV, An M, Newby GA, Chen JC, Hsu A, Liu DR. Engineered pegRNAs improve prime editing efficiency. Nat Biotechnol, 2022, 40(3): 402-410. doi: 10.1038/s41587-021-01039-7
[16]	Jiang YY, Chai YP, Lu MH, Han XL, Lin QP, Zhang Y, Zhang Q, Zhou Y, Wang XC, Gao CX, Chen QJ. Prime editing efficiently generates W542L and S621I double mutations in two ALS genes in maize. Genome Biol, 2020, 21(1): 257. doi: 10.1186/s13059-020-02170-5
[17]	Zhuang Y, Liu JL, Wu H, Zhu QG, Yan YC, Meng HW, Chen PR, Yi CQ. Increasing the efficiency and precision of prime editing with guide RNA pairs. Nat Chem Biol, 2022, 18(1): 29-37. doi: 10.1038/s41589-021-00889-1
[18]	Song M, Lim JM, Min S, Oh JS, Kim DY, Woo JS, Nishimasu H, Cho SR, Yoon S, Kim HH. Generation of a more efficient prime editor 2 by addition of the Rad51 DNA-binding domain. Nat Commun, 2021, 12(1): 5617. doi: 10.1038/s41467-021-25928-2 pmid: 34556671
[19]	Park SJ, Jeong TY, Shin SK, Yoon DE, Lim SY, Kim SP, Choi J, Lee H, Hong JI, Ahn J, Seong JK, Kim K. Targeted mutagenesis in mouse cells and embryos using an enhanced prime editor. Genome Biol, 2021, 22(1): 170. doi: 10.1186/s13059-021-02389-w
[20]	Chen PJ, Hussmann JA, Yan J, Knipping F, Ravisankar P, Chen PF, Chen CD, Nelson JW, Newby GA, Sahin M, Osborn MJ, Weissman JS, Adamson B, Liu DR. Enhanced prime editing systems by manipulating cellular determinants of editing outcomes. Cell, 2021, 184(22): 5635-5652.e29. doi: 10.1016/j.cell.2021.09.018 pmid: 34653350
[21]	Xu W, Yang YX, Yang BY, Krueger CJ, Xiao QL, Zhao S, Zhang L, Kang GT, Wang FP, Yi HM, Ren W, Li L, He XQ, Zhang CM, Zhang B, Zhao JR, Yang JX. A design optimized prime editor with expanded scope and capability in plants. Nat Plants, 2022, 8(1): 455-52. doi: 10.1038/s41477-022-01143-9
[22]	Zong Y, Liu YJ, Xue CX, Li BS, Li XY, Wang YP, Li J, Liu GW, Huang XX, Cao XF, Gao CX. An engineered prime editor with enhanced editing efficiency in plants. Nat Biotechnol, 2022.
[23]	Kweon J, Yoon JK, Jang AH, Shin HR, See JE, Jang GY, Kim JI, Kim Y. Engineered prime editors with PAM flexibility. Mol Ther, 2021, 29(6): 20015-2007.
[24]	Peterka M, Akrap N, Li SY, Wimberger S, Hsieh PP, Degtev D, Bestas B, Barr J, van de Plassche S, Mendoza- Garcia P, Šviković S, Sienski G, Firth M, Maresca M. Harnessing DSB repair to promote efficient homology- dependent and -independent prime editing. Nat Commun, 2022, 13(1): 1240. doi: 10.1038/s41467-022-28771-1 pmid: 35332138
[25]	Ferreira da Silva J, Oliveira GP, Arasa-Verge EA, Kagiou C, Moretton A, Timelthaler G, Jiricny J, Loizou JI. Prime editing efficiency and fidelity are enhanced in the absence of mismatch repair. Nat Commun, 2022, 13(1): 760. doi: 10.1038/s41467-022-28442-1 pmid: 35140211
[26]	Adikusuma F, Lushington C, Arudkumar J, Godahewa GI, Chey YCJ, Gierus L, Piltz S, Geiger A, Jain Y, Reti D, Wilson LOW, Bauer DC, Thomas PQ. Optimized nickase- and nuclease-based prime editing in human and mouse cells. Nucleic Acids Res, 2021, 49(18): 107855-10795.
[27]	Tao R, Wang YH, Hu Y, Jiao YG, Zhou LF, Jiang LR, Li L, He XY, Li M, Yu YM, Chen Q, Yao SH. WT-PE: prime editing with nuclease wild-type Cas9 enables versatile large-scale genome editing. Signal Transduct Target Ther, 2022, 7(1): 108.
[28]	Wang JL, He Z, Wang GQ, Zhang RW, Duan JY, Gao P, Lei XL, Qiu HY, Zhang CP, Zhang Y, Yin H. Efficient targeted insertion of large DNA fragments without DNA donors. Nat Methods, 2022, 19(3): 3315-340.
[29]	Jiang TT, Zhang XO, Weng ZP, Xue W. Deletion and replacement of long genomic sequences using prime editing. Nat Biotechnol, 2022, 40(2): 2275-234.
[30]	Li XS, Zhou LN, Gao BQ, Li GY, Wang X, Wang Y, Wei J, Han WY, Wang ZX, Li JF, Gao RZ, Zhu JJ, Xu WC, Wu J, Yang B, Sun XD, Yang L, Chen J. Highly efficient prime editing by introducing same-sense mutations in pegRNA or stabilizing its structure. Nat Commun, 2022, 13(1): 1669. doi: 10.1038/s41467-022-29339-9 pmid: 35351879
[31]	Petri K, Zhang WT, Ma JY, Schmidts A, Lee H, Horng JE, Kim DY, Kurt IC, Clement K, Hsu JY, Pinello L, Maus MV, Joung JK, Yeh JJ. CRISPR prime editing with ribonucleoprotein complexes in zebrafish and primary human cells. Nat Biotechnol, 2022, 40(2): 1895-193.
[32]	Lin QP, Jin S, Zong Y, Yu H, Zhu ZX, Liu GW, Kou LQ, Wang YP, Qiu JL, Li JY, Gao CX. High-efficiency prime editing with optimized, paired pegRNAs in plants. Nat Biotechnol, 2021, 39(8): 9235-927.
[33]	Liu PP, Liang SQ, Zheng CW, Mintzer E, Zhao YG, Ponnienselvan K, Mir A, Sontheimer EJ, Gao GP, Flotte TR, Wolfe SA, Xue W. Improved prime editors enable pathogenic allele correction and cancer modelling in adult mice. Nat Commun, 2021, 12(1): 2121. doi: 10.1038/s41467-021-22295-w pmid: 33837189
[34]	Liu B, Dong XL, Cheng HY, Zheng CW, Chen ZX, Rodríguez TC, Liang SQ, Xue W, Sontheimer EJ. A split prime editor with untethered reverse transcriptase and circular RNA template. Nat Biotechnol, 2022.
[35]	Zheng CW, Liang SQ, Liu B, Liu PP, Kwan SY, Wolfe SA, Xue W. A flexible split prime editor using truncated reverse transcriptase improves dual-AAV delivery in mouse liver. Mol Ther, 2022, 30(3): 13435-1351.
[36]	Oh Y, Lee WJ, Hur JK, Song WJ, Lee Y, Kim H, Gwon LW, Kim YH, Park YH, Kim CH, Lim KS, Song BS, Huh JW, Kim SU, Jun BH, Jung C, Lee SH. Expansion of the prime editing modality with Cas9 from Francisella novicida. Genome Biol, 2022, 23(1): 92. doi: 10.1186/s13059-022-02644-8 pmid: 35410288
[37]	Anzalone AV, Gao XD, Podracky CJ, Nelson AT, Koblan LW, Raguram A, Levy JM, Mercer JAM, Liu DR. Programmable deletion, replacement, integration and inversion of large DNA sequences with twin prime editing. Nat Biotechnol, 2022, 40(5): 7315-740.
[38]	Choi J, Chen W, Suiter CC, Lee C, Chardon FM, Yang W, Leith A, Daza RM, Martin B, Shendure J. Precise genomic deletions using paired prime editing. Nat Biotechnol, 2022, 40(2): 2185-226.
[39]	Bosch JA, Birchak G, Perrimon N. Precise genome engineering in Drosophila using prime editing. Proc Natl Acad Sci USA, 2021, 118(1): e2021996118.
[40]	Qian YQ, Zhao D, Sui TT, Chen M, Liu ZQ, Liu HM, Zhang T, Chen SY, Lai LX, Li ZJ. Efficient and precise generation of Tay-Sachs disease model in rabbit by prime editing system. Cell Discov, 2021, 7(1): 50. doi: 10.1038/s41421-021-00276-z pmid: 34230459
[41]	Tong YJ, Jørgensen TS, Whitford CM, Weber T, Lee SY. A versatile genetic engineering toolkit for E. coli based on CRISPR-prime editing. Nat Commun, 2021, 12(1): 5206. doi: 10.1038/s41467-021-25541-3
[42]	Butt H, Rao GS, Sedeek K, Aman R, Kamel R, Mahfouz M. Engineering herbicide resistance via prime editing in rice. Plant Biotechnol J, 2020, 18(12): 23705-2372.
[43]	Geurts MH, de Poel E, Pleguezuelos-Manzano C, Oka R, Carrillo L, Andersson-Rolf A, Boretto M, Brunsveld JE, van Boxtel R, Beekman JM, Clevers H. Evaluating CRISPR-based prime editing for cancer modeling and CFTR repair in organoids. Life Sci Alliance, 2021, 4(10): e202000940.
[44]	Li HY, Li JY, Chen JL, Yan L, Xia LQ. Precise modifications of both exogenous and endogenous genes in rice by prime editing. Mol Plant, 2020, 13(5): 6715-674.
[45]	Lu YM, Tian YF, Shen RD, Yao Q, Zhong DT, Zhang XN, Zhu JK. Precise genome modification in tomato using an improved prime editing system. Plant Biotechnol J, 2021, 19(3): 4155-417.
[46]	Wang L, Kaya HB, Zhang N, Rai RT, Willmann MR, Carpenter SCD, Read AC, Martin F, Fei ZJ, Leach JE, Martin GB, Bogdanove AJ.Spelling changes and fluorescent tagging with prime editing vectors for plants. Front Genome Ed, 2021, 3: 617553.
[47]	Perroud PF, Guyon-Debast A, Veillet F, Kermarrec MP, Chauvin L, Chauvin JE, Gallois JL, Nogué F. Prime editing in the model plant physcomitrium patens and its potential in the tetraploid potato. Plant Sci, 2022, 316: 111162. doi: 10.1016/j.plantsci.2021.111162
[48]	Xu RF, Liu XS, Li J, Qin RY, Wei PC. Identification of herbicide resistance OsACC1 mutations via in planta prime-editing-library screening in rice. Nat Plants, 2021, 7(7): 8885-892.
[49]	Erwood S, Bily TMI, Lequyer J, Yan J, Gulati N, Brewer RA, Zhou LC, Pelletier L, Ivakine EA, Cohn RD. Saturation variant interpretation using CRISPR prime editing. Nat Biotechnol, 2022, 40(6): 8855-895.
[50]	Böck D, Rothgangl T, Villiger L, Schmidheini L, Matsushita M, Mathis N, Ioannidi E, Rimann N, Grisch-Chan HM, Kreutzer S, Kontarakis Z, Kopf M, Thöny B, Schwank G. In vivo prime editing of a metabolic liver disease in mice. Sci Transl Med, 2022, 14(636): eabl9238. doi: 10.1126/scitranslmed.abl9238
[51]	Li JN, Liu Z, Huang SS, Wang X, Li GL, Xu YT, Yu WX, Chen SS, Zhang Y, Ma HH, Ke ZF, Chen J, Sun Q, Huang XX. Efficient base editing in G/C-rich regions to model androgen insensitivity syndrome. Cell Res, 2019, 29(2): 1745-176.
[52]	Liu Z, Lu ZY, Yang G, Huang SS, Li GL, Feng SJ, Liu YJ, Li JN, Yu WX, Zhang Y, Chen J, Sun Q, Huang XX. Efficient generation of mouse models of human diseases via ABE- and BE-mediated base editing. Nat Commun, 2018, 9(1): 2338. doi: 10.1038/s41467-018-04768-7 pmid: 29904106
[53]	Gao P, Lyu Q, Ghanam AR, Lazzarotto CR, Newby GA, Zhang W, Choi M, Slivano OJ, Holden K, Walker JA,2nd, Kadina AP, Munroe RJ, Abratte CM, Schimenti JC, Liu DR, Tsai SQ, Long XC, Miano JM. Prime editing in mice reveals the essentiality of a single base in driving tissue-specific gene expression. Genome Biol, 2021, 22(1): 83. doi: 10.1186/s13059-021-02304-3 pmid: 33722289
[54]	Xiang GH, Ren JL, Hai T, Fu R, Yu DW, Wang J, Li W, Wang HY, Zhou Q. Editing porcine IGF2 regulatory element improved meat production in Chinese Bama pigs. Cell Mol Life Sci, 2018, 75(24): 46195-4628.
[55]	Crispo M, Mulet AP, Tesson L, Barrera N, Cuadro F, dos Santos-Neto PC, Nguyen TH, Crénéguy A, Brusselle L, Anegón I, Menchaca A. Efficient generation of myostatin knock-out sheep using CRISPR/Cas9 technology and microinjection into zygotes. PLoS One, 2015, 10(8).
[56]	Li GW, Zhou SW, Li C, Cai B, Yu HH, Ma BH, Huang Y, Ding YG, Liu Y, Ding Q, He C, Zhou JK, Wang Y, Zhou GX, Li Y, Yan Y, Hua JL, Petersen B, Jiang Y, Sonstegard T, Huang XX, Chen YL, Wang XL. Base pair editing in goat: nonsense codon introgression into FGF5 results in longer hair. FEBS J, 2019, 286(23): 46755-4692.
[57]	Lv QY, Yuan L, Deng JC, Chen M, Wang Y, Zeng J, Li ZJ, Lai LX.Efficient generation of myostatin gene mutated rabbit by CRISPR/Cas9. Sci Rep, 2016, 6: 25029. doi: 10.1038/srep25029 pmid: 27113799
[58]	Wang XL, Yu HH, Lei AM, Zhou JK, Zeng WX, Zhu HJ, Dong ZM, Niu YY, Shi BB, Cai B, Liu JW, Huang S, Yan HL, Zhao X, Zhou GX, He XL, Chen XX, Yang YX, Jiang Y, Shi L, Tian X, Wang YJ, Ma BH, Huang XX, Qu L, Chen YL. Generation of gene-modified goats targeting MSTN and FGF5 via zygote injection of CRISPR/Cas9 system. Sci Rep, 2015, 5: 13878. doi: 10.1038/srep13878 pmid: 26354037
[59]	Whitworth KM, Rowland RRR, Ewen CL, Trible BR, Kerrigan MA, Cino-Ozuna AG, Samuel MS, Lightner JE, McLaren DG, Mileham AJ, Wells KD, Prather RS. Gene-edited pigs are protected from porcine reproductive and respiratory syndrome virus. Nat Biotechnol, 2016, 34(1): 205-22.
[60]	Sun JY, Sun KX, Ding YG, Zhou SW, Gao YW, Chen YL, Wang XL. Editing efficiency of four single base editors in sheep (Ovis aries) and goat (Capra hircus) fibroblasts. J Agric Biotechnol, 2021, 29(1): 1695-177.
	孙嘉媛, 孙珂欣, 丁一格, 周世卫, 高亚伟, 陈玉林, 王小龙. 四种单碱基编辑器在羊成纤维细胞上的编辑效率. 农业生物技术学报, 2021, 29(1): 1695-177.
[61]	Niu XR, Yin SM, Chen X, Shao TT, Li DL. Gene editing technology and its recent progress in disease therapy. Hereditas (Beijing), 2019, 41(7): 5825-598.
	牛煦然, 尹树明, 陈曦, 邵婷婷, 李大力. 基因编辑技术及其在疾病治疗中的研究进展. 遗传, 2019, 41(7): 5825-598.
[62]	Gillmore JD, Gane E, Taubel J, Kao J, Fontana M, Maitland ML, Seitzer J, O'Connell D, Walsh KR, Wood K, Phillips J, Xu YX, Amaral A, Boyd AP, Cehelsky JE, McKee MD, Schiermeier A, Harari O, Murphy A, Kyratsous CA, Zambrowicz B, Soltys R, Gutstein DE, Leonard J, Sepp-Lorenzino L, Lebwohl D. CRISPR-Cas9 in vivo gene editing for transthyretin amyloidosis. N Engl J Med, 2021, 385(6): 4935-502.
[63]	Schene IF, Joore IP, Oka R, Mokry M, van Vugt AHM, van Boxtel R, van der Doef HPJ, van der Laan LJW, Verstegen MMA, van Hasselt PM, Nieuwenhuis EES, Fuchs SA. Prime editing for functional repair in patient- derived disease models. Nat Commun, 2020, 11(1): 5352. doi: 10.1038/s41467-020-19136-7 pmid: 33097693
[64]	Chemello F, Chai AC, Li H, Rodriguez-Caycedo C, Sanchez-Ortiz E, Atmanli A, Mireault AA, Liu N, Bassel- Duby R, Olson EN. Precise correction of Duchenne muscular dystrophy exon deletion mutations by base and prime editing. Sci Adv, 2021, 7(18).
[65]	Kim Y, Hong SA, Yu J, Eom J, Jang K, Yoon S, Hong DH, Seo D, Lee SN, Woo JS, Jeong J, Bae S, Choi D. Adenine base editing and prime editing of chemically derived hepatic progenitors rescue genetic liver disease. Cell Stem Cell, 2021, 28(9): 16145-1624.e5.
[66]	Lu YM, Zhu JK. Precise editing of a target base in the rice genome using a modified CRISPR/Cas9 system. Mol Plant, 2017, 10(3): 5235-525.
[67]	Zong Y, Wang YP, Li C, Zhang R, Chen KL, Ran YD, Qiu JL, Wang DW, Gao CX. Precise base editing in rice, wheat and maize with a Cas9-cytidine deaminase fusion. Nat Biotechnol, 2017, 35(5): 4385-440.
[68]	Hua K, Tao XP, Han PJ, Wang R, Zhu JK. Genome engineering in rice using Cas9 variants that recognize NG PAM sequences. Mol Plant, 2019, 12(7): 10035-1014.
[69]	Li JY, Sun YW, Du JL, Zhao YD, Xia LQ. Generation of targeted point mutations in rice by a modified CRISPR/ Cas9 system. Mol Plant, 2017, 10(3): 5265-529.
[70]	Zhang R, Liu JX, Chai ZZ, Chen S, Bai Y, Zong Y, Chen KL, Li JY, Jiang LJ. Gao CX. Generation of herbicide tolerance traits and a new selectable marker in wheat using base editing. Nature Plants, 2019, 5(5): 4805-485.
[71]	Qin RY, Wei PC. Prime editing creates a novel dimension of plant precise genome editing. Hereditas (Beijing), 2020, 42(6): 5195-523.
	秦瑞英, 魏鹏程. Prime editing引导植物基因组精确编辑新局面. 遗传, 2020, 42(6): 519-523.
[72]	Tang X, Sretenovic S, Ren QR, Jia XY, Li MK, Fan TT, Yin DS, Xiang SY, Guo YC, Liu L, Zheng XL, Qi YP, Zhang Y. Plant prime editors enable precise gene editing in rice cells. Mol Plant, 2020, 13(5): 6675-670.
[73]	Xu RF, Li J, Liu XS, Shan TF, Qin RY, Wei PC. Development of plant prime-editing systems for precise genome editing. Plant Commun, 2020, 1(3): 100043. doi: 10.1016/j.xplc.2020.100043
[74]	Xu W, Zhang CW, Yang YX, Zhao S, Kang GT, He XQ, Song JL, Yang JX. Versatile nucleotides substitution in plant using an improved prime editing system. Mol Plant, 2020, 13(5): 6755-678.
[75]	Wang T, Wei JJ, Sabatini DM, Lander ES. Genetic screens in human cells using the CRISPR-Cas9 system. Science, 2014, 343(6166): 805-84.
[76]	Hanna RE, Hegde M, Fagre CR, DeWeirdt PC, Sangree AK, Szegletes Z, Griffith A, Feeley MN, Sanson KR, Baidi Y, Koblan LW, Liu DR, Neal JT, Doench JG. Massively parallel assessment of human variants with base editor screens. Cell, 2021, 184(4): 10645-1080.e20.
[77]	Cuella-Martin R, Hayward SB, Fan X, Chen X, Huang JW, Taglialatela A, Leuzzi G, Zhao JF, Rabadan R, Lu C, Shen Y, Ciccia A. Functional interrogation of DNA damage response variants with base editing screens. Cell, 2021, 184(4): 10815-1097.e19.
[78]	Findlay GM, Boyle EA, Hause RJ, Klein JC, Shendure J. Saturation editing of genomic regions by multiplex homology-directed repair. Nature, 2014, 513(7516): 1205-123.
[79]	Zhi SY, Chen YX, Wu GL, Wen JK, Wu JN, Liu QY, Li Y, Kang R, Hu SH, Wang JH, Liang PP, Huang JJ. Dual-AAV delivering split prime editor system for in vivo genome editing. Mol Ther, 2022, 30(1): 2835-294.
[80]	Banskota S, Raguram A, Suh S, Du SW, Davis JR, Choi EH, Wang X, Nielsen SC, Newby GA, Randolph PB, Osborn MJ, Musunuru K, Palczewski K, Liu DR. Engineered virus-like particles for efficient in vivo delivery of therapeutic proteins. Cell, 2022, 185(2): 2505-265.e16.
[81]	Pensado A, Seijo B, Sanchez A. Current strategies for DNA therapy based on lipid nanocarriers. Expert Opin Drug Deliv, 2014, 11(11): 17215-1731.
[82]	Lee K, Conboy M, Park HM, Jiang FG, Kim HJ, Dewitt MA, Mackley VA, Chang K, Rao A, Skinner C, Shobha T, Mehdipour M, Liu H, Huang WC, Lan F, Bray NL, Li S, Corn JE, Kataoka K, Doudna JA, Conboy I, Murthy N. Nanoparticle delivery of Cas9 ribonucleoprotein and donor DNA in vivo induces homology-directed DNA repair. Nat Biomed Eng, 2017, 1: 8895-901.
[83]	Hsu JY, Grünewald J, Szalay R, Shih J, Anzalone AV, Lam KC, Shen MW, Petri K, Liu DR, Joung JK, Pinello L. PrimeDesign software for rapid and simplified design of prime editing guide RNAs. Nat Commun, 2021, 12(1): 1034. doi: 10.1038/s41467-021-21337-7 pmid: 33589617
[84]	Hwang GH, Jeong YK, Habib O, Hong SA, Lim K, Kim JS, Bae S. PE-Designer and PE-Analyzer: web-based design and analysis tools for CRISPR prime editing. Nucleic Acids Res, 2021, 49(W1): W4995-W504.
[85]	Li YC, Chen JJ, Tsai SQ, Cheng Y. Easy-Prime: a machine learning-based prime editor design tool. Genome Biol, 2021, 22(1): 235. doi: 10.1186/s13059-021-02458-0 pmid: 34412673
[86]	Anderson MV, Haldrup J, Thomsen EA, Wolff JH, Mikkelsen JG. PegIT—a web-based design tool for prime editing. Nucleic Acids Res, 2021, 49(W1): W5055-W509.
[87]	Standage-Beier K, Tekel SJ, Brafman DA, Wang X. Prime editing guide RNA eesign automation using PINE- CONE. ACS Synth Biol, 2021, 10(2): 4225-427.
[88]	Siegner SM, Karasu ME, Schroder MS, Kontarakis Z, Corn JE. PnB Designer: a web application to design prime and base editor guide RNAs for animals and plants. BMC Bioinformatics, 2021, 22(1): 101. doi: 10.1186/s12859-021-04034-6 pmid: 33653259
[89]	Chow RD, Chen JS, Shen J, Chen S. A web tool for the design of prime-editing guide RNAs. Nat Biomed Eng, 2021, 5(2): 1905-194.
[90]	Kim HK, Yu G, Park J, Min S, Lee S, Yoon S, Kim HH. Predicting the efficiency of prime editing guide RNAs in human cells. Nat Biotechnol, 2021, 39(2): 1985-206.
[91]	Clement K, Rees H, Canver MC, Gehrke JM, Farouni R, Hsu JY, Cole MA, Liu DR, Joung JK, Bauer DE, Pinello L. CRISPResso 2 provides accurate and rapid genome editing sequence analysis. Nat Biotechnol, 2019, 37(3): 2245-226.
[92]	Jin S, Lin QP, Luo YF, Zhu ZX, Liu GW, Li YJ, Chen KL, Qiu JL, Gao CX. Genome-wide specificity of prime editors in plants. Nat Biotechnol, 2021, 39(10): 12925-1299.
[93]	Kim DY, Moon SB, Ko JH, Kim YS, Kim D. Unbiased investigation of specificities of prime editing systems in human cells. Nucleic Acids Res, 2020, 48(18): 105765-10589.
[94]	Gao RZ, Fu ZC, Li XY, Wang Y, Wei J, Li GY, Wang LJ, Wu J, Huang XX, Yang L, Chen J. Genomic and transcriptomic analyses of prime editing guide RNA-independent off-target effects by prime editors. CRISPR J, 2022, 5(2): 2765-293.
[95]	Aida T, Wilde JJ, Yang L, Hou Y, Li M, Xu D, Lin J, Qi P, Lu Z, Feng G. Prime editing primarily induces undesired outcomes in mice. biorxiv, 2020.
[96]	Musunuru K, Chadwick AC, Mizoguchi T, Garcia SP, DeNizio JE, Reiss CW, Wang K, Iyer S, Dutta C, Clendaniel V, Amaonye M, Beach A, Berth K, Biswas S, Braun MC, Chen HM, Colace TV, Ganey JD, Gangopadhyay SA, Garrity R, Kasiewicz LN, Lavoie J, Madsen JA, Matsumoto Y, Mazzola AM, Nasrullah YS, Nneji J, Ren H, Sanjeev A, Shay M, Stahley MR, Fan SHY, Tam YK, Gaudelli NM, Ciaramella G, Stolz LE, Malyala P, Cheng CJ, Rajeev KG, Rohde E, Bellinger AM, Kathiresan S. In vivo CRISPR base editing of PCSK 9 durably lowers cholesterol in primates. Nature, 2021, 593(7859): 4295-434.
[97]	Koblan LW, Erdos MR, Wilson C, Cabral WA, Levy JM, Xiong ZM, Tavarez UL, Davison LM, Gete YG, Mao XJ, Newby GA, Doherty SP, Narisu N, Sheng QH, Krilow C, Lin CY, Gordon LB, Cao K, Collins FS, Brown JD, Liu DR. In vivo base editing rescues Hutchinson-Gilford progeria syndrome in mice. Nature, 2021, 589(7843): 6085-614.

编辑推荐

Metrics

www.chinagene.cn
备案号：京ICP备09063187号-4
总访问:,今日访问:,当前在线:

版本名称	优化策略	编辑效率及相应细胞	参考文献
ePE	抑制pegRNA环化	>80% (HEK293T)	[12]
epegRNA	抑制pegRNA降解	>80% (HEK293T)	[15]
xrPE	抑制pegRNA降解	>80% (HEK293T)	[13]
G-PE	抑制pegRNA降解	>70% (HEK293T)	[14]
spegRNA/apegRNA	RTT上引入同义突变/改变pegRNA二级结构	>80% (HEK293T)	[30]
—	增强pegRNA的表达	>50% (玉米细胞)	[16]
Dual-pegRNA	使用两条pegRNA来编码反向互补的逆转录产物	>40% (水稻细胞)	[32]
HOPE	使用成对的pegRNA	>30% (HCT116)	[17]
CMP-PE3	调节染色质结构	>47% (小鼠胚胎)	[19]
hyPE2	融合表达功能元件	>43% (HEK293T)	[18]
PE-P2/PE-P3	nCas9 N端融合RT，RTT上设计多碱基替换	>59% (水稻细胞)	[21]
PEmax	密码子优化，融合蛋白结构优化等	>30% (HEK293T)	[20]
PE2 *	增加核定位信号	>6% (小鼠肝脏)	[33]
ePPE	删除RT的RNase H结构域，添加病毒核衣壳蛋白	>25% (水稻细胞)	[22]
spCas9-NG等	利用识别不同PAM的Cas9变体构建PE系统	>50% (HEK293T)	[23]
Fn_PE3	利用FnCas9构建PE系统	>80% (HEK293FT)	[36]
PE4/PE5	调节DNA修复途径	>60% (HEK293T)	[20]
—	调节DNA修复途径	>40% (HEK293)	[25]

技术名称	改造策略	用途	Cas蛋白	PAM类型	参考文献
TwinPE	两条相向的pegRNA来逆转录出互补的DNA链	大片段的替换、插入或删除	nCas9	NGG	[37]
PRIME-Del	使用一对相向的pegRNA	精准删除大片段	nCas9	NGG	[38]
GRAND	使用一对相向的pegRNA	精准插入长片段	nCas9	NGG	[28]
PEn	Cas9和逆转录酶融合表达	小片段插入	Cas9	NGG	[24]
PEDAR	Cas9和逆转录酶融合表达	大片段删除与替换	Cas9	NGG	[29]
PEA1	Cas9和逆转录酶融合，多组分同一质粒表达	点突变、插入、删除	Cas9	NGG	[26]
WT-PE	Cas9和逆转录酶融合并结合成对pegRNA	大片段删除，染色体易位	Cas9	NGG	[27]

软件名称	特点	网址	参考文献
PrimeDesign	可进行高通量设计	http://primedesign.pinellolab.org/	[83]
PE-Designer	设计的同时展示潜在脱靶位点	http://www.rgenome.net/pe-designer/	[84]
Easy-Prime	基于机器学习优化pegRNA	http://easy-prime.cc/	[85]
PlantPegDesigner	优选双pegRNA策略	http://www.plantgenomeediting.net	[32]
pegIT	设计的同时展示潜在脱靶位点	https://pegit.giehmlab.dk	[86]
PINE-CONE	可进行高通量设计	https://github.com/xiaowanglab/PINE-CONE	[87]
PnB Designer	支持PE、CBE和ABE的gRNA设计	http://fgcz-shiny.uzh.ch/PnBDesigner/	[88]
pegFinder	可对pegRNA进行打分排序	http://pegfinder.sidichenlab.org	[89]

引导编辑：突破碱基编辑类型的新技术

Prime editing: a search and replace tool with versatile base changes

RichHTML

PDF (PC)

可视化

摘要/Abstract

引用本文

使用本文

图/表 6

参考文献 97

相关文章 15

编辑推荐

Metrics

[1]	王秉政, 张超, 张佳丽, 孙锦. 利用单转录本表达Cas9和sgRNA条件性编辑果蝇基因组[J]. 遗传, 2023, 45(7): 593-601.
[2]	刘梅珍, 王立人, 李咏梅, 马雪云, 韩红辉, 李大力. 利用CRISPR/Cas9技术构建基因编辑大鼠模型[J]. 遗传, 2023, 45(1): 78-87.
[3]	张潇筠, 徐坤, 沈俊岑, 穆璐, 钱泓润, 崔婕妤, 马宝霞, 陈知龙, 张智英, 魏泽辉. 一种新型提高HDR效率的CRISPR/Cas9-Gal4BD供体适配基因编辑系统[J]. 遗传, 2022, 44(8): 708-719.
[4]	张充, 魏子璇, 王敏, 陈瑶生, 何祖勇. 利用CRISPR/Cas9在人类黑色素瘤细胞中编辑MC1R与功能分析[J]. 遗传, 2022, 44(7): 581-590.
[5]	时子文, 何青, 赵卓凡, 刘孝伟, 张鹏, 曹墨菊. 玉米雄性不育资源的发掘与利用[J]. 遗传, 2022, 44(2): 134-152.
[6]	韩玉婷, 许博文, 李羽童, 卢心怡, 董习之, 邱雨浩, 车沁耘, 朱芮葆, 郑丽, 李孝宸, 司绪, 倪建泉. 模式动物果蝇的基因调控前沿技术[J]. 遗传, 2022, 44(1): 3-14.
[7]	杨光武, 田嫄. 果蝇F-box基因Ppa促进脂肪储存[J]. 遗传, 2021, 43(6): 615-622.
[8]	彭定威, 李瑞强, 曾武, 王敏, 石翾, 曾检华, 刘小红, 陈瑶生, 何祖勇. 编辑MSTN半胱氨酸节基元促进两广小花猪肌肉生长[J]. 遗传, 2021, 43(3): 261-270.
[9]	王娜, 甲芝莲, 吴强. RFX5调控原钙粘蛋白α基因簇的表达[J]. 遗传, 2020, 42(8): 760-774.
[10]	李国玲, 杨善欣, 吴珍芳, 张献伟. 提高CRISPR/Cas9介导的动物基因组精确插入效率研究进展[J]. 遗传, 2020, 42(7): 641-656.
[11]	陈赢男, 陆静. CRISPR/Cas9系统在林木基因编辑中的应用[J]. 遗传, 2020, 42(7): 657-668.
[12]	刘思远, 易国强, 唐中林, 陈斌. 基于CRISPR/Cas9系统在全基因组范围内筛选功能基因及调控元件研究进展[J]. 遗传, 2020, 42(5): 435-443.
[13]	鲍莉雯, 周一叶, 曾凡一. 基于CRISPR/Cas9技术的β-地中海贫血和血友病基因治疗研究进展[J]. 遗传, 2020, 42(10): 949-964.
[14]	林珉婷, 赖璐璐, 赵淼, 林必玮, 姚香平. 利用CRISPR/Cas9 AAV系统构建纹状体Slc20a2基因敲除小鼠模型[J]. 遗传, 2020, 42(10): 1017-1027.
[15]	刘沛峰, 吴强. CRISPR/Cas9基因编辑在三维基因组研究中的应用[J]. 遗传, 2020, 42(1): 18-31.
