适于检测非洲猪瘟病毒的点亮Spinach-p54 RNA适配体的设计及应用

doi:10.16288/j.yczz.21-335

遗传 ›› 2021, Vol. 43 ›› Issue (12): 1170-1178.doi: 10.16288/j.yczz.21-335

适于检测非洲猪瘟病毒的点亮Spinach-p54 RNA适配体的设计及应用

韩程程^1,²(), 夏凯^1,³, 龚茹莹¹, 吴栩涵¹, 张蕾^1,²(), 梁新乐^1,²()

1. 浙江工商大学食品与生物工程学院,杭州 310018
2. 浙江工商大学食品生物工程研究所,杭州 310018
3. 浙江科技学院生物与化学工程学院,杭州 310023

收稿日期:2021-09-21 修回日期:2021-11-30 出版日期:2021-12-20 发布日期:2021-12-10
通讯作者: 张蕾,梁新乐 E-mail:707884766@qq.com;zhanglei@zjsu.edu.cn;dbiot@mail.zjgsu.edu.cn
作者简介:韩程程,博士研究生,研究方向：食品生物技术。E-mail: 707884766@qq.com

Design and application of lightening Spinach-p54 RNA apatmer to detect African swine fever virus

Han Chengcheng^1,²(), Xia Kai^1,³, Gong Ruying¹, Wu Xuhan¹, Zhang Lei^1,²(), Liang Xinle^1,²()

1. School of Food Science and Biotechnology, Zhejiang Gongshang University, Hangzhou 310018, China
2. Institute of Food Biotechnology, Zhejiang Gongshang University, Hangzhou 310018, China
3. School of Biological and Chemical Engineering, Zhejiang University of Science and Technology, Hangzhou 310023, China

Received:2021-09-21 Revised:2021-11-30 Online:2021-12-20 Published:2021-12-10
Contact: Zhang Lei,Liang Xinle E-mail:707884766@qq.com;zhanglei@zjsu.edu.cn;dbiot@mail.zjgsu.edu.cn

摘要/Abstract

摘要：

非洲猪瘟病毒(African swine fever virus, ASFV)是近年来流行的一种主要致病病毒,对我国的国民经济生活造成了严重影响。本研究以非洲猪瘟病毒的编码保守蛋白p54基因序列片段为检测目标,结合点亮 Spinach RNA适配体的开关功能,设计了Spinach-p54的嵌合式RNA适配体。其特异地结合目标序列并产生荧光,实现了在RNA水平上对非洲猪瘟病毒的快速检测。研究结果表明,核酸适配体浓度200 nmol/L,反应温度为37 ℃,该方法检出限为200 nmol/L,线性范围为200~400 nmol/L。该方法特异性强,操作简单,灵敏度高等特点,可用于市场和养殖场的现场快速检测。

关键词: 核酸适配体, RNA, turn-on, 非洲猪瘟

Abstract:

African swine fever virus (ASFV) is a major and prevalent pathogenic virus in livestock. Its outbreak in the recent years has seriously affected the national economic life. In this study, a specific chimeric RNA aptamer Spinach-p54 corresponding to the conserved protein p54 of ASFV, was designed and used in assembling a toehold RNA module with a truncated lightening Spinach switch. They were used to detect the p54 gene. The aptamer bound rapidly and paired specifically with the ASFV p54 target sequence and produced fluorescence with the addition of DFHBI substrate. The results showed that the limit of detection was as low as 200 nmol/L p54 fragment, under the conditions of 200 nmol/L Spinach-p54 aptamer and 37 ℃, suggesting that the current method can provide a simple, specific, sensitive, and rapid on-site detection of ASFV at the RNA level in the markets and farms.

Key words: aptamer, RNA, turn-on, African swine fever viru

韩程程, 夏凯, 龚茹莹, 吴栩涵, 张蕾, 梁新乐. 适于检测非洲猪瘟病毒的点亮Spinach-p54 RNA适配体的设计及应用[J]. 遗传, 2021, 43(12): 1170-1178.

Han Chengcheng, Xia Kai, Gong Ruying, Wu Xuhan, Zhang Lei, Liang Xinle. Design and application of lightening Spinach-p54 RNA apatmer to detect African swine fever virus[J]. Hereditas(Beijing), 2021, 43(12): 1170-1178.

图/表 9

图1

表1

图2

表2

图3

图4

图5

图6

图7

参考文献 35

[1]	Normile D. Arrival of deadly pig disease could spell disaster for China. Science, 2018,361(6404):741.
[2]	Ma J, Chen H, Gao X, Xiao JH, Wang HB. African swine fever emerging in China: distribution characteristics and high-risk areas. Prev Vet Med, 2020,175:104861.
[3]	Galindo I, Alonso C. African swine fever virus: a review. Viruses, 2017,9(5):103.
[4]	Giudici SD, Franzoni G, Bonelli P, Bacciu D, Sanna G, Angioi PP, Ledda M, Pilo G, Nicolussi P, Oggiano A. Interaction of historical and modern Sardinian African swine fever viruses with porcine and wild-boar monocytes and monocyte-derived macrophages. Arch Virol, 2019,164(3):739-745.
[5]	Yang F, Cheng LQ, Xu XG, Zhang WM, Zhang Q. Establishment and preliminary application of a real-time fluorescence quantitative PCR for CSFV detection. Prog Vet Med, 2021,42(1):1-5.
	杨峰, 陈立强, 许信刚, 张为民, 张琪. 猪瘟病毒实时荧光定量PCR检测方法的建立及初步应用. 动物医学进展, 2021,42(1):1-5.
[6]	Zhu YS, Shao N, Chen JW, Qi WB, Li Y, Liu P, Chen YJ, Bian SY, Zhang Y, Tao SC. Multiplex and visual detection of African swine fever virus (ASFV) based on Hive-Chip and direct loop-mediated isothermal amplification. Anal Chim Acta, 2020,1140:30-40.
[7]	Guinat C, Gogin A, Blome S, Kei G, Pollin R, Pfeiffer DU, Dixon L. Transmission routes of African swine fever virus to domestic pigs: current knowledge and future research directions. Vet Rec, 2016,178(11):262-267.
[8]	Wang ZY, Dan K, Shi YG, Kan SF, Zhong LX, He QH. Research progress on rapid detection methods of African swine fever virus. Food Safe Qual Detec Technol, 2020,11(10):3215-3220.
	王梓莹, 但琨, 施远国, 阚式绂, 钟雷响, 何庆华. 非洲猪瘟病毒的快速检测方法研究进展. 食品安全质量检测学报, 2020,11(10):3215-3220.
[9]	Cui BB, Li T, Qiu SY, Mei L, Han XQ, Wu SQ. Establishment of a real-time PCR for detection of African swine fever virus E184L gene. Prog Vet Med, 2020,41(1):8-14.
	崔贝贝, 李霆, 仇松寅, 梅琳, 韩雪清, 吴绍强, 林祥梅. 基于E184L基因的非洲猪瘟病毒实时荧光定量PCR检测方法的建立. 动物医学进展, 2020,41(1):8-14.
[10]	Wang SJ, Liu MF, Yan RQ, Ban FG, Zhao XL, Ma ZY, Wang HJ, Wang C, Zhao MJ. Establishment and application of real-time quantitative PCR assay for detection of classical Swine fever virus. Chin Anim Husb Vet Med, 2017,44(7):2112-2118.
	王淑娟, 刘梅芬, 闫若潜, 班付国, 赵雪丽, 马震原, 王华俊, 王翠, 赵明军. 猪瘟病毒实时荧光定量PCR检测方法的建立与应用. 中国畜牧兽医, 2017,44(7):2112-2118.
[11]	Yan L, Song S, Zhang JH, Tang XL, Zhang HY, Guo KP. Establishment and application of droplet digital PCR for detection of African swine fever virus. Acta Laser Biol Sin, 2020,29(4):344-351.
	严礼, 宋晟, 张继红, 唐小兰, 张海韵, 郭焜鹏. 非洲猪瘟病毒微滴式数字PCR检测方法的建立与应用. 激光生物学报, 2020,29(4):344-351.
[12]	Bergeron HC, Glas PS, Schumann KR. Diagnostic specificity of the African swine fever virus antibody detection enzyme-linked immunosorbent assay in feral and domestic pigs in the United States. Transbound Emerg Dis, 2017,64(6):1665-1668.
[13]	Huang J, Huang JJ, Cheng XF, Li GX, Gao F, Tong GZ. Expression of p30 protein of African swine fever virus in prokaryotic cells and preparation of polyclonal antibodies. Chin J Vet Parasitol, 2020,28(5):37-41.
	黄剑, 徐晶晶, 程雪飞, 李国新, 高飞, 童光志. 非洲猪瘟病毒p30蛋白的原核表达及其多克隆抗体制备. 中国动物传染病学报, 2020,28(5):37-41.
[14]	Liu XT, Wang ZY, Xin T, Guo XY, Jiang YT, Cui S, Yu HN, Zhu HF, Jia H. Prokaryotic expression and polyclonal antibody preparation and identification of African swine fever virus B438L protein. Chin Anim Husb Vet Med, 2021,48(3):991-1000.
	刘雪婷, 王召阳, 鑫婷, 郭晓宇, 姜一曈, 崔帅, 于海男, 朱鸿飞, 贾红. 非洲猪瘟病毒B438L蛋白的原核表达及其多克隆抗体的制备与鉴定. 中国畜牧兽医, 2021,48(3):991-1000.
[15]	Bouhedda F, Autour A, Ryckelynck M. Light-up RNA aptamers and their cognate fluorogens: from their development to their applications. Int J Mol Sci, 2017,19(1):44.
[16]	Rogers TA, Andrews GE, Jaeger L, Grabow WW. Fluorescent monitoring of RNA assembly and processing using the split-spinach aptamer. ACS Synth Biol, 2015,4(2):162-166.
[17]	Chandler M, Lyalina T, Halman J, Rackley L, Lee L, Dang D, Ke WN, Sajja S, Woods S, Acharya S, Baumgarten E, Christopher J, Elshalia E, Hrebien G, Kublank K, Saleh S, Stallings B, Tafere M, Striplin C, Afonin KA. Broccoli fluorets: split aptamers as a user-friendly fluorescent toolkit for dynamic RNA nanotechnology. Molecules, 2018,23(12):3178.
[18]	Kikuchi N, Kolpashchikov DM. Split Spinach aptamer for highly selective recognition of DNA and RNA at ambient temperatures. ChemBioChem, 2016,17(17):1589-1592.
[19]	Ausländer S, Fuchs D, Hürlemann S, Ausländer D, Fussenegger M. Engineering a ribozyme cleavage-induced split fluorescent aptamer complementation assay. Nucleic Acids Res, 2016,44(10):e94.
[20]	Ong WQ, Citron YR, Sekine S, Huang B. Live cell imaging of endogenous mRNA using RNA-based fluorescence “Turn-On” probe. ACS Chem Biol, 2017,12(1):200-205.
[21]	Bhadra S, Ellington AD. Design and application of cotranscriptional non-enzymatic RNA circuits and signal transducers. Nucleic Acids Res, 2014,42(7):e58.
[22]	Gui HL, Jin QR, Zhang YJ, Wang XD, Yang YC, Shao CY, Cheng CY, Wei FF, Yang Y, Yang MH, Song HH. Development of an aptamer/fluorescence dye PicoGreen-based method for detection of fumonisin B1. Chin J Biotech, 2015,31(9):1393-1400.
	桂海娈, 金庆日, 张亚军, 王晓杜, 杨永春, 邵春艳, 程昌勇, 卫芳芳, 杨杨, 杨梦华, 宋厚辉. 基于荧光染料PicoGreen和核酸适配体的伏马毒素B1检测方法. 生物工程学报, 2015,31(9):1393-1400.
[23]	Fernandez-Millan P, Autour A, Ennifar E, Westhof E, Ryckelynck M. Crystal structure and fluorescence properties of the iSpinach aptamer in complex with DFHBI. RNA, 2017,23(12):1788-1795.
[24]	Huang H, Suslov NB, Li NS, Shelke SA, Evans ME, Koldobskaya Y, Rice PA, Piccirilli JA. A G-quadruplex- containing RNA activates fluorescence in a GFP-like fluorophore. Nat Chem Biol, 2014,10(8):686-691.
[25]	Truong L, Ferré-D'Amaré AR. From fluorescent proteins to fluorogenic RNAs: tools for imaging cellular macromolecules. Protein Sci, 2019,28(8):1374-1386.
[26]	Matsunaga KI, Kimoto M, Lim VW, Thein TL, Vasoo S, Leo YS, Sun W, Hirao I. Competitive ELISA for a serologic test to detect dengue serotype-specific anti-NS1 IgGs using high-affinity UB-DNA aptamers. Sci Rep, 2021,11(1):18000.
[27]	Chen H, Park SG, Choi N, Kwon HJ, Kang T, Lee MK, Choo J. Sensitive detection of SARS-CoV-2 using a SERS-based aptasensor. ACS Sens, 2021,6(6):2378-2385.
[28]	Jeng SCY, Chan HHY, Booy EP, McKenna SA, Unrau PJ. Fluorophore ligand binding and complex stabilization of the RNA Mango and RNA Spinach aptamers. RNA, 2016,22(12):1884-1892.
[29]	Filonov GS, Moon JD, Svensen N, Jaffrey SR. Broccoli: rapid selection of an RNA mimic of green fluorescent protein by fluorescence-based selection and directed evolution. J Am Chem Soc, 2014,136(46):16299-16308.
[30]	Parra-Guardado AL, Sweeney CL, Hayes EK, Trueman BF, Huang Y, Jamieson RC, Rand JL, Gagnon GA, Stoddart AK. Development of a rapid pre-concentration protocol and a magnetic beads-based RNA extraction method for SARS-CoV-2 detection in raw municipal wastewater. Environ Sci: Water Res Technol, 2021.
[31]	Modh H, Scheper T, Walter JG. Aptamer-modified magnetic beads in biosensing. Sensors (Basel), 2018,18(4):1041.
[32]	Wei Y, Li K, Lu DR, Zhu HX. Optimization of CUT&Tag product recovery and library construction method. Hereditas(Beijing), 2021,43(4):362-374.
	韦晔, 李科, 卢大儒, 朱化星. CUT&Tag产物回收和建库方法的优化. 遗传, 2021,43(4):362-374.
[33]	Wang Y, Xu LZ, Noll L, Stoy C, Porter E, Fu JP, Feng Y, Peddireddi L, Liu XM, Dodd KA, Jia W, Bai JF. Development of a real-time PCR assay for detection of African swine fever virus with an endogenous internal control. Transbound Emerg Dis, 2020,67(6):2446-2454.
[34]	Fu JY, Zhang YP, Cai G, Meng G, Shi SB. Rapid and sensitive RPA-Cas12a-fluorescence assay for point-of-care detection of African swine fever virus. PLoS One, 2021,16(7):e0254815.
[35]	Wang XJ, Ji PP, Fan HY, Dang L, Wan WW, Liu SY, Li YH, Yu WX, Li XY, Ma XD, Ma X, Zhao Q, Huang XX, Liao M. CRISPR/Cas12a technology combined with immunochromatographic strips for portable detection of African swine fever virus. Commun Biol, 2020,3(1):62.

编辑推荐

Metrics

www.chinagene.cn
备案号：京ICP备09063187号-4
总访问:,今日访问:,当前在线:

适配体名称	序列(5′→3′)
Spinach-p54-1	GATGCCGCGGATGGCGAAGGACGGGTCCAGTGCGTTCGCGCACTGTTGAGTAGAGTGTGAGCGCCAAACCGGTTGA
Spinach-p54-2	ACTGTCGTGTATGGCGAAGGACGGGTCCAGTGCGTTCGCGCACTGTTGAGTAGAGTGTGAGCGCCAGGCTCAGTCG
Spinach-p54-3	CCATAATGCCGTGGCGAAGGACGGGTCCAGTGCGTTCGCGCACTGTTGAGTAGAGTGTGAGCGCCCGGATAAACCG

RNA适配体名称	单链适配体最小自由能(kcal/mol)	与p54 RNA结合后最小自由能(kcal/mol)
Spinach-p54-1	-24.2	-52.88
Spinach-p54-2	-27.4	-51.38
Spinach-p54-3	-24.5	-46.28
